Cisco Modeling Labs (CML) 2.5 comes with annotations, a new characteristic for all CML license ranges. When studying and planning, annotations allow you get the most out of your labs. Annotations permit you to include all the documentation on how parts of the network get the job done, details about your understanding targets and up coming methods, or approaches the community elements in good shape together. In quick, the annotations element in CML 2.5 lets you make your network yours. Here’s how it is effective.

Incorporate context with annotations in CML

Annotations enable you to provide extra context to your lab topology and organize the factors in a handy, meaningful way. For instance, you can use annotations to clearly show routing, IP addressing, and VLAN facts, as shown below: Annotations in CML are persistent. This implies annotations will be provided in the lab definition if exported, permitting you to share your annotated labs with other individuals.

A grid history and node/annotation grid snapping are enabled by default. Snapping will automatically snap nodes and annotations to be certain they are correctly aligned when drawing or going them. You can switch off snapping for a lab by unchecking the snap to grid solution in the toolbar configurations. You can also quickly disable snapping by keeping the Alt vital when you insert or move a node/annotation.

Also, annotations assistance transparency and layering, making it possible for you to stack annotations.

How to insert annotations to labs in CML 2.5

You can add annotations to labs in the workbench by way of one particular of the four annotation applications in the toolbar.

 There is one particular software for each and every variety of annotation:

1. Rectangle
2. Ellipsis
3. Text
4. Line

For all annotation forms besides textual content, you can incorporate the annotations by 1st selecting the instrument. Then click on and hold the mouse exactly where you want the annotation to get started, and drag it to in which you want it to finish. Releasing the mouse will create the annotation, and you will see a sidebar with other properties you can transform for the annotation.

The approach of adding a textual content annotation is related, setting up with picking out the instrument. Future, simply click and launch in which you want the text. Eventually, the sidebar will open up, allowing for you to enter the textual content you want to use.

New possibilities in toolbar settings

Simply click the equipment icon in the toolbar to open up the canvas options menu, which gives these new choices for CML 2.5:

1. Toggles the grid on/off
2. Turns node/annotation snapping on/off
3. Turns annotations off, hiding the drawn annotations and annotation instruments

Note: You can quickly disable the snap-to-grid alternative by keeping the Alt crucial (or Possibility essential on a Mac) when moving or resizing an annotation/node. This lets you keep snapping enabled though precisely placing an annotation/node.

 Edit annotations

Picking out an annotation will toggle the visibility of the resize handles for the at the moment selected annotation. Furthermore, a sidebar will be opened, enabling you to edit the annotation houses even further

1. Resize Handles
2. Sidebar

Long term annotations in CML

The CML enhancement team is presently exploring adding an picture annotation variety in a potential release to let the addition of pictures inside a topology.

What do you consider of annotations? How can we boost?

Share your thoughts in the Cisco Modeling Labs Neighborhood on the Cisco Discovering Network now.
